PDF下載產品參數(shù)
| 型號 Model |
單位 Unit |
CZJ2-4 | CZJ2-5 |
| 額定電壓 Rated Voltage |
DC.V | 12 | 12 |
| 工作電壓 Working Voltage |
DC.V | 9~16 | 9~16 |
| 電阻 Resistance |
(25℃) Ω/相 |
60±7% | 30±10% |
| 減速比 Reduction Ratio |
1:295.56 | 1:400 | |
| 執(zhí)行器轉速 Actuatorspeed |
RPM | 2~5 | 2~5 |
| 牽出轉矩 Pull-out torque |
mN.m | ≥98 | ≥700 |
| 步距角 (電機) Step angle(motor) |
° | 15 | 15 |
| 步距角 (輸出軸) Step angle(output shaft) |
° | 0.0508 | 0.0375 |
| 輸出軸轉速 (output shaft speed) |
r/min | 5 | 2.0 |
| 保持轉矩 Holding torque |
N.cm | ≥100 | ≥100 |
| 工作溫度 Working Temperature |
℃ | -40~85 | -40~85 |
| 防護等級 Protection level |
IP50 | IP50 | |
| 絕緣介電強度 Dielectric Strength |
無擊穿或飛弧 No breakdown or flashover AC600V,1mA,1s |
無擊穿或飛弧 No breakdown or flashover AC500V,3mA,1min |
|
| 絕緣電阻 Insolution Resistance |
DC500V(MΩ) | ≥100 | ≥100 |
| 溫升 Temperature rise |
K | ≤65 | ≤65 |
| 噪音 Noise |
dB(A) | ≤35 (10cm) |
≤35 (10cm) |
| 通訊方式 Communication mode |
LIN2.X | LIN2.X |
機械尺寸
